Industrial CT (Computed Tomography) Scanning

Industrial CT scanning is an advanced, non-destructive inspection method that uses X-rays and specialized reconstruction techniques to provide intricate 3D visualizations of internal structures of a product.

Industrial CT (Computed Tomography) Scanning is a critical, advanced inspection technique used primarily by manufacturers, particularly those in the medical device industry, to detect defects, perform quality assurance, and support risk mitigation efforts.

It is emerging as a powerful tool for quality assurance in 3D-printed medical devices and serves as a robust line of defense for manufacturers in safeguarding patient safety and reliability.

Frequently Asked Questions (FAQs) Associated with Industrial CT Scanning

1. What problems or defects does Industrial CT Scanning help detect and analyze?

Industrial CT scanning offers high-resolution 3D images that allow manufacturers to inspect complex assemblies in situ (in place). It is highly effective at detecting internal defects that traditional methods miss.

It is specifically mentioned as a breakthrough solution for identifying and analyzing:

• Leaky connectors and seals.
• Assembly misalignment, even down to fractions of a millimeter, particularly in intricate assemblies like drug delivery systems or pacemakers.
• Material failures and structural weaknesses.
• Additive manufacturing anomalies (defects specific to 3D printing) such as porosity, incomplete fusion between layers, and variations in material density.
• Minuscule cracks, defects, or misalignments that are invisible to the naked eye or undetectable by traditional methods.

2. How does Industrial CT improve upon Traditional Inspection Techniques?

Traditional techniques have significant limitations that Industrial CT overcomes:

• Visual Inspection: This method is inherently limited by human capabilities and can overlook microscopic defects or surface irregularities.
• Coordinate Measuring Machines (CMM): CMMs are primarily suited for measuring external dimensions and are less effective for inspecting the complex, internal geometries of medical devices.
• 2D X-ray Inspection: This is commonly used to evaluate internal structure, but it may miss subtle defects because it provides only 2D imaging, lacking comprehensive 3D data.
• Fluorescent Penetrant Inspection (FPI): FPI is primarily effective at detecting surface defects and is far less effective for detecting hidden defects beneath surfaces, where Industrial CT excels.
• Ultrasonic Testing (UT): While useful for internal defects, UT can struggle with surface defects or irregularities, potentially compromising device performance.

Industrial CT scanning performs a non-destructive and highly detailed method of inspecting components, offering a three-dimensional analysis that thoroughly examines intricate internal structures.

3. What role does Industrial CT play in Risk Management and Quality Improvement?

Industrial CT scanning acts as a powerful tool for continuous quality improvement and risk mitigation for medical device manufacturers.

• Early Risk Mitigation: By allowing manufacturers to quickly detect and accurately analyze defects at an early stage, Industrial CT minimizes the potential for costly recalls. It can be used to perform Root Cause Analysis (RCA) and derivation of critical measurements from flawed parts, enabling manufacturers to take precise corrective actions.
• Continuous Monitoring: CT scanning can be seamlessly integrated into routine quality control processes. This is used for "Routine process monitoring" to maintain consistent product quality and verify the dimensional accuracy of intricate geometries.
• Supplier Quality: CT can be used at scale in production to evaluate supplier quality, ensuring that defective components never make it into the final assembly of a medical device.
• Advanced Analysis: CT scans provide insights into the structural integrity of device components. With associated software, engineers can compare scanned parts to CAD models to quantify deviations, helping to address issues of material integrity.

4. What technology exists for implementing Industrial CT Scanning?

The sources highlight accessible, advanced technology for Industrial CT:

• Neptune: An Industrial CT scanner designed to be an everyday engineering tool with an easy-to-use touchscreen interface and AI-driven scan configuration. It can run on a standard 120V outlet and is suitable for use in an office or workshop environment.
• Voyager: Analysis software that visualizes scans in a browser-based platform. It allows users to pinpoint issues, share notes, and leverage AI engine expertise (Atlas) to suggest solutions.
• Triton: A production-scale CT system designed to quickly load, scan, and exchange parts, while automating decision-making to minimize human error.

‍
